Presentación de imágenes de fantasía con efectos de transición de triangulación de Delaunay

Vista prévia

Descripción

Un HTML5 Canvas basado en una presentación de imagen de fantasía que cambia automáticamente entre imágenes con efectos de transición de triangulación de Delaunay fresco. Construido con < a href = "https://github.com/ironwallaby/delaunay" target = "_ blank" rel = "noopener" > Delaunay. js y < a href = "http://greensock.com/tweenmax" target = "_ blank" rel = "noopener" > TweenMax .

Funcionamiento

Crear un elemento DIV vacío que se servirá como un contenedor de presentación de diapositivas.

<div id="container"></div>

Cargue el Delaunay. js y la biblioteca TweenMax JS en la parte inferior de la Página Web.

<script src="delaunay.js"></script>
<script src="//cdnjs.cloudflare.com/ajax/libs/gsap/1.14.1/TweenMax.min.js"></script>

Agregue los estilos CSS necesarios en el documento.

canvas {

position: absolute;

backface-visibility: hidden;

-webkit-backface-visibility: hidden;

-moz-backface-visibility: hidden;

-ms-backface-visibility: hidden;
}

img {

position: absolute;

-webkit-transition: opacity .3s;

transition: opacity .3s;
}

El código JavaScript para agregar sus imágenes a la proyección de diapositivas y activar los efectos de transición de triangulación de Delaunay.

const TWO_PI = Math.PI * 2;

var images = [],

 imageIndex = 0;

var image,

imageWidth = 768,

imageHeight = 485;

 var vertices = [],

indices = [],

prevfrag = [],

fragments = [];

var margin = 50;

var container = document.getElementById('container');

var clickPosition = [imageWidth * 0.5, imageHeight * 0.5];

window.onload = function() {

TweenMax.set(container, {perspective:500});


// images from http://www.hdwallpapers.in

var urls = [



'1.jpg',



'2.jpg',



'3.jpg',



'4.jpg'


],


image,


loaded = 0;

// very quick and dirty hack to load and display the first image asap

images[0] = image = new Image();


image.onload = function() {



if (++loaded === 1) {









for (var i = 1; i < 4; i++) {





images[i] = image = new Image();






image.src = urls[i];




}




 placeImage();



}


};


image.src = urls[0];
 };

function placeImage(transitionIn) {

image = images[imageIndex];


if (++imageIndex === images.length) imageIndex = 0;



var num = Math.random();

if(num < .25) {


image.direction = "left";

} else if(num < .5) {


image.direction = "top";

} else if(num < .75) {


image.direction = "bottom";

} else {


image.direction = "right";

}


container.appendChild(image);

image.style.opacity = 0;



if (transitionIn !== false) {


triangulateIn();

}
}

function triangulateIn(event) {

var box = image.getBoundingClientRect(),


top = box.top,


left = box.left;



if(image.direction == "left") {


clickPosition[0] = 0;


 clickPosition[1] = imageHeight / 2;

} else if(image.direction == "top") {


clickPosition[0] = imageWidth / 2;


clickPosition[1] = 0;

} else if(image.direction == "bottom") {


clickPosition[0] = imageWidth / 2;


clickPosition[1] = imageHeight;

} else if(image.direction == "right") {


clickPosition[0] = imageWidth;


clickPosition[1] = imageHeight / 2;

}




 triangulate();

build();
}

function triangulate() {

for(var i = 0; i < 40; i++) {




x = -margin + Math.random() * (imageWidth + margin * 2);


y = -margin + Math.random() * (imageHeight + margin * 2);


vertices.push([x, y]);

}

vertices.push([0,0]);

vertices.push([imageWidth,0]);

vertices.push([imageWidth, imageHeight]);

vertices.push([0, imageHeight]);



vertices.forEach(function(v) {


v[0] = clamp(v[0], 0, imageWidth);


v[1] = clamp(v[1], 0, imageHeight);

});



indices = Delaunay.triangulate(vertices);
}

function build() {

var p0, p1, p2,


fragment;


var tl0 = new TimelineMax({onComplete:buildCompleteHandler});


for (var i = 0; i < indices.length; i += 3) {


p0 = vertices[indices[i + 0]];


p1 = vertices[indices[i + 1]];


p2 = vertices[indices[i + 2]];



fragment = new Fragment(p0, p1, p2);



var dx = fragment.centroid[0] - clickPosition[0],



dy = fragment.centroid[1] - clickPosition[1],



d = Math.sqrt(dx * dx + dy * dy),



rx = 30 * sign(dy),



ry = 90 * -sign(dx),



delay = d * 0.003 * randomRange(0.9, 1.1);


fragment.canvas.style.zIndex = Math.floor(d).toString();



var tl1 = new TimelineMax();



 if(image.direction == "left") {



rx = Math.abs(rx);



 ry = 0;





} else if(image.direction == "top") {



rx = 0;



ry = Math.abs(ry);


} else if(image.direction == "bottom") {



rx = 0;



ry = - Math.abs(ry);


} else if(image.direction == "right") {



rx = - Math.abs(rx);



ry = 0;


}





 tl1.from(fragment.canvas, 1, {




z:-50,




rotationX:rx,




rotationY:ry,




scaleX:0,




scaleY:0,




ease:Cubic.easeIn


 });


tl1.from(fragment.canvas, 0.4,{alpha:0}, 0.6);





tl0.insert(tl1, delay);



fragments.push(fragment);


container.appendChild(fragment.canvas);

}
}

function buildCompleteHandler() {

// add pooling?

image.style.opacity = 1;

image.addEventListener('transitionend', function catchTrans() {


fragments.forEach(function(f) {



container.removeChild(f.canvas);


});



fragments.length = 0;


vertices.length = 0;


indices.length = 0;



placeImage();


this.removeEventListener('transitionend',catchTrans,false);

}, false);


}

//////////////
// MATH UTILS
//////////////

function randomRange(min, max) {

return min + (max - min) * Math.random();
}

function clamp(x, min, max) {

return x < min ? min : (x > max ? max : x);
}

function sign(x) {

return x < 0 ? -1 : 1;
}

//////////////
// FRAGMENT
//////////////

Fragment = function(v0, v1, v2) {

this.v0 = v0;

this.v1 = v1;

this.v2 = v2;


this.computeBoundingBox();

this.computeCentroid();

this.createCanvas();

this.clip();
};
Fragment.prototype = {

computeBoundingBox:function() {


var xMin = Math.min(this.v0[0], this.v1[0], this.v2[0]),



xMax = Math.max(this.v0[0], this.v1[0], this.v2[0]),



yMin = Math.min(this.v0[1], this.v1[1], this.v2[1]),



yMax = Math.max(this.v0[1], this.v1[1], this.v2[1]);



 this.box = {



x:Math.round(xMin),



y:Math.round(yMin),



w:Math.round(xMax - xMin),



h:Math.round(yMax - yMin)


};


},

computeCentroid:function() {


var x = (this.v0[0] + this.v1[0] + this.v2[0]) / 3,



y = (this.v0[1] + this.v1[1] + this.v2[1]) / 3;



this.centroid = [x, y];

},

createCanvas:function() {


this.canvas = document.createElement('canvas');


this.canvas.width = this.box.w;


this.canvas.height = this.box.h;


this.canvas.style.width = this.box.w + 'px';


this.canvas.style.height = this.box.h + 'px';


this.canvas.style.left = this.box.x + 'px';


this.canvas.style.top = this.box.y + 'px';


this.ctx = this.canvas.getContext('2d');

},

clip:function() {


this.ctx.save();


this.ctx.translate(-this.box.x, -this.box.y);


this.ctx.beginPath();


this.ctx.moveTo(this.v0[0], this.v0[1]);


this.ctx.lineTo(this.v1[0], this.v1[1]);


this.ctx.lineTo(this.v2[0], this.v2[1]);


this.ctx.closePath();


this.ctx.clip();


this.ctx.drawImage(image, 0, 0);


this.ctx.restore();

}
};
